C PURLINS and C GIRTS


C Purlin and C Girt Structural Steel

Wind, Snow, & Weight Tables

Flexospan provides standard, even-profile C purlins and C girts as well as custom profiles and punching patterns. We manufacture any component from 1/2" steel subgirts to 12" section up to 10 gauge.  Steel c purlins and c girts are also available with other depths and flange widths. Contact Flexospan for information on purlin and girt structural steel dimensions. Steel wall girts and roof purlins are manufactured and sold onsite.


Cee Purlin and C Girt Structural Steel


Purlin & Girt Coatings:

  • Prime Painted

  • Galvanized

  • Stainless Steel

  • ZAM




Roof purlins are used to support metal roofing panels.  Wall girts are used for the fastening of metal siding.  They are available in stainless steel or galvanized, and can be prime painted and/or coated in ZAM.

In this section you'll find sample calculations for determining wind and snow loads as well as
C purlin and C girt weight tables.


icon-pdf C AND Z SPAN LOAD TABLE Cee Purlin and C Girt Structural Steel

icon-pdf C PURLIN AND GIRT SECTION PROPERTIES

icon-pdf STANDARD HOLE PUNCHING PATTERNS


Sample Calculations
Calculation Formula Example
Wind load (sizing girts)
Wind load (lbs/sq ft) x .75 x girt spacing (ft) x wind coefficient (typically 1.1) = Allowable load/linear foot of girt



20 psf x .75 x 5 Ft x 1.1 = 82.5 plf


Live (snow) Load
(load on purlin)
Snow load (lbs/sq ft) x purlin spacing (ft) = allowable load/linear foot of purlin 20 psf x 5 ft = 100 plf
Note: These sample calculations are basic. Many different variables can affect loading. For example, drift loading, building height, geographic location, etc. Please contact Flexospan if special conditions exist.
C Purlin and C Girt Weight Table: Weight per Linear Foot
16 Gauge

14 Gauge

12 Gauge

Size (nom)

2 1/2" Fl 3 1/2" Fl 2 1/2" Fl 3 1/2" Fl 2 1/2" Fl 3 1/2" Fl
6" Cee 2.656 N/A 3.281 N/A 4.531 N/A
8 " Cee 3.099 3.541 3.828 4.375

5.286

6.041
10" Cee 3.541 3.984 4.375 4.922 6.041 6.797
12 " Cee 3.984 N/A 4.922 5.468 6.797 7.552
Note: These weights are for three or more spans based on uniform bay spacings. Contact Flexospan for help on calculating weights for non-uniform bays.
